This innovative C-PVC fire sprinkler system is a cost-effective, high-performance alternative to metal piping. Made from a corrosion-resistant compound, it offers excellent hydraulics, easy solvent cement installation, and long-term durability. UL listed and compliant with NFPA 13, 13R, and 13D standards, it suits residential buildings, schools, hotels, and hospitals. The system includes pipes (¾" to 3"), UL-listed fittings, and solvent cement. With superior flow, resistance to scaling and MIC, and high pressure ratings, this solution ensures reliable fire protection while reducing installation time and costs significantly compared to traditional metal fire sprinkler systems.
Nominal Size | Inch | Outside Diameter 'D' (mm) | Wall Thickness 't' (mm) SDR 13.5 |
Working Pressure | ||
---|---|---|---|---|---|---|
Avg. | Tolerance | Min | Tolerance | |||
20 | ¾" | 26.7 | ±0.10 | 1.98 | 0.51 | 12 bar @ 65°C 22 bar @ 23°C |
25 | 1" | 33.4 | ±0.10 | 2.46 | 0.51 | |
32 | 1¼" | 42.2 | ±0.10 | 3.12 | 0.51 | |
40 | 1½" | 48.2 | ±0.10 | 3.58 | 0.51 | |
50 | 2" | 60.3 | ±0.10 | 4.47 | 0.53 | |
65 | 2½" | 73.0 | ±0.10 | 5.41 | 0.66 | |
80 | 3" | 88.9 | ±0.20 | 6.58 | 0.79 |
